Punching Tools


     whether you need standard or special shapes, thick or thin turret, Amada or Strippit style. Our products features designed to improve your piece part quality maximize productivity and enhance a longer tool life and greater performance.
Punch Press Tooling
Material  001 Cr12Mov = SKD11
Heat treatment HRC 60°-  62°
Material 002 W6Mo5Cr4v2 = M2 = SKH51
Heat treatment HRC 61°-  63°
                              Package Plastic Package & Wooden Crate
                              Delivery time 3 - 5  workdays

Advantages:

  1. Small distortion of material;
  2. High endurance surface, longer tool life;
  3. Nice interchangeability;
  4. Smooth molding, Fast adjustability
  5. Competitive Price, Fast Delivery.
  6. ISO-9001:2000 certificate



Remark:

(1) Material 001: Cr12Mov = SKD11

The Chemical Composition of Cr12Mov
C Si Mn Cr Mo P S V
1.45~1.70 ≤0.40 ≤0.35 11.0~12.50 0.40~0.60 ≤0.030 ≤0.030 0.15~0.30
HRC60°-62°
Thickness can be processed: Hot-Rolled Steel & cold rolled steel (3 - 6 mm)

(2) Material 002: W6Mo5Cr4v2 = M2 = SKH51

The Chemical Composition of W6Mo5Cr4v2
C Mn Si Cr V W Mo P S
0.8~0.9 0.15~0.4 0.2~0.45 3.8~4.4 1.75~2.2 5.5~6.75 4.5~5.5 ≤ 0.03 ≤ 0.03
HRC61°- 63°

Notices:
(1)     The height of molding is higher; the phenomenon of “reverse pulling” is more serious.
(2)     For panels that are smaller than 1.2, the Rc should be over 10mm so as to pretend the angle from spiltting.
(3)     The interval space(A)for non-molding should not be less than 3 times of the panel thickness.

Molding mould advantages:
1. Small distortion of material;
2. Nice Interchangeability;
3. Smooth molding;
4. Fast adjustabilitycompany info
